Ferolite NAM-35 CR can be supplied as Full Sheet, Custom Size Cut Sheet, flange gaskets, Ring gaskets, Custom Gaskets, strips, Blocks, washers.
Ferolite NAM-32 CR is a specialized gasket material renowned for its exceptional chemical resistance, resilience to high temperatures, and versatility across various industrial applications.
Our services extend to precision cutting of this material into various forms such as flange or ring gaskets, customized to your specific needs. Alternatively, we welcome your designs or samples for tailored production. Moreover, we can supply this material in sheet1500mm x 2000mm.
Here’s a detailed description of Ferolite NAM-32 CR:
Composition: Ferolite NAM-32 CR is a non-asbestos gasket material composed of a blend of compressed aramid fibers and NBR (Nitrile Butadiene Rubber) binder. This composition provides a balance of mechanical strength, flexibility, and chemical resistance necessary for effective sealing in demanding applications.
Chemical Resistance: Ferolite NAM-32 CR exhibits excellent resistance to a wide range of chemicals, including acids, alkalis, solvents, oils, and fuels. This chemical resistance makes it suitable for use in industries where exposure to corrosive substances is common, such as chemical processing, petrochemicals. This material is suitable for various highly different aggressive media and very good chemical resistance to acid & alkaline media.
High Temperature Resistance: The aramid fibers in Ferolite NAM-32 CR provide exceptional thermal stability, allowing the gasket material to withstand temperatures ranging from cryogenic levels up to 270°C in continuous service. .
Mechanical Strength: Despite its flexibility, Ferolite NAM-32 CR maintains excellent mechanical strength and dimensional stability, ensuring reliable sealing performance even under high bolt loads and compressive forces. This mechanical resilience contributes to the gasket material’s longevity and durability in demanding applications.
Flexibility and Conformability: Ferolite NAM-32 CR is highly flexible and conformable, allowing it to adapt to irregular flange surfaces and create a tight seal. Its ability to conform to surface imperfections ensures leak-free performance in critical sealing applications.
In summary, Ferolite NAM-32 CR offers exceptional chemical resistance, high temperature resistance, mechanical strength, and versatility, making it a preferred choice for demanding sealing applications where reliability and performance are paramount.
Material Composition : Aramid Fibre
- Max.Peak Temp : 400°C
- Max. Continuous Temp : 270°C
- Max.Continuous Temp.with steam : 240°C
- Max. Operating Pressure : 150 Kg/cm2
- Material Thickness: 1.5, 3.0 mm
- Sheet Size: 1500mm x 2000mm
To place an order or if you require any further more information, please simply click here to Call Us or Email US.
